SNR-N8P Industrial Mini PC
SNR-N8P is a compact fanless industrial mini PC designed for self-service kiosks, digital signage, automation control, machine vision and embedded commercial applications. It supports Intel Core i3 / i5 / i7 processor options from 4th to 13th generation, dual GbE LAN, RS232 COM ports, USB, HDMI / VGA display output, Mini-PCIe expansion, M.2 SSD storage, 12–19V DC input and Windows / Linux operating systems.
"*" indicates required fields
SNR-N8P Fanless Industrial Mini PC for Self-Service Kiosks, Digital Signage and Embedded Automation
The SNR-N8P industrial mini PC is a compact fanless embedded computer designed for self-service kiosks, digital signage, industrial automation, machine vision, network appliances and commercial embedded systems.
With a rugged aluminium passive-cooling chassis, Intel Core processor options from 4th to 13th generation, dual GbE LAN, USB ports, RS232 COM ports, HDMI / VGA display output and 12–19V DC wide-voltage input, SNR-N8P provides a reliable computing platform for 24/7 operation in space-limited industrial and commercial environments.
Key Features
- Compact fanless industrial mini PC
- Aluminium passive-cooling chassis
- Intel 4th / 6th / 7th / 8th / 10th / 12th / 13th Gen Core i3 / i5 / i7 processor options
- Supports DDR3L, DDR4 or DDR5 memory depending on CPU platform
- Dual GbE RJ45 LAN ports
- 4 × USB 3.0 and 4 × USB 2.0 ports
- 2 × RS232 COM ports for industrial and peripheral devices
- HDMI + VGA or HDMI + HDMI dual display support
- Mini-PCIe expansion for WiFi, Bluetooth, 3G / 4G modules
- M.2 2280 SATA / NVMe SSD support on newer platforms
- 2.5 inch HDD / SSD bay for additional storage
- Watchdog timer and diskless startup support
- 12–19V DC wide-voltage input
- Operating temperature: -20℃ to 60℃
- Compact size: 193.9 × 127 × 57.2mm
- Desktop or wall-mount installation
Applications
- Self-service kiosk controller
- Self-ordering kiosk
- Self-checkout kiosk
- Ticketing kiosk
- Patient check-in kiosk
- Card dispenser kiosk
- Digital signage player
- Retail display system
- Industrial automation control
- Machine vision system
- Human-machine interface
- Data acquisition system
- Network security appliance
- Firewall / VPN gateway
- Medical equipment
- Embedded Linux / Windows system
- Commercial automation equipment
Technical Specifications
System
| Item | Specification |
|---|---|
| Model | SNR-N8P |
| Product Type | Fanless Industrial Mini PC |
| Processor | Intel 4th / 6th / 7th / 8th / 10th / 12th / 13th Gen Core i3 / i5 / i7 |
| Chipset | Integrated with CPU |
| OS Support | Windows 7 / 8 / 10 / 11, WES 7 / 10, Linux |
| Watchdog Timer | Supported |
| Diskless Startup | Supported |
Memory and Storage
| Platform | Memory Support | Storage Support |
|---|---|---|
| 4th Gen | DDR3L SODIMM × 1, max 8GB | 1 × mSATA + 1 × 2.5 inch HDD / SSD |
| 6th / 7th Gen | DDR4 SODIMM × 1, max 16GB | 1 × M.2 2280 SATA / NVMe + 1 × 2.5 inch HDD / SSD |
| 8th / 10th Gen | DDR4 SODIMM × 2, max 32GB | 1 × M.2 2280 SATA / NVMe + 1 × 2.5 inch HDD / SSD |
| 12th / 13th Gen | DDR5 SODIMM × 1, max 64GB | 1 × M.2 2280 SATA / NVMe + 1 × 2.5 inch HDD / SSD |
I/O Interfaces
| Interface | Specification |
|---|---|
| USB 3.0 | 4 × USB 3.0 |
| USB 2.0 | 4 × USB 2.0 |
| COM Ports | 2 × RS232 |
| LAN | 2 × GbE RJ45 |
| Display | 1 × HDMI + 1 × VGA or second HDMI |
| Audio | 1 × headphone, 1 × microphone |
| Antenna Ports | 2 × antenna ports for WiFi / 3G / 4G |
| Power Button | 1 × front-access power button |
Expansion and Connectivity
| Slot | Support |
|---|---|
| Mini-PCIe | 1 × half-card / full-card with SIM slot |
| Wireless Expansion | WiFi / Bluetooth / 3G / 4G |
| M.2 2280 | SATA or NVMe SSD |
| 2.5 Inch Drive Bay | HDD or SSD |
Power and Environment
| Item | Specification |
|---|---|
| Power Input | 12–19V DC |
| Operating Temperature | -20℃ to 60℃ |
| Storage Temperature | -30℃ to 70℃ |
| Storage Humidity | 10%–90% @ 30℃, non-condensing |
Mechanical Specifications
| Item | Specification |
|---|---|
| Material | Aluminium |
| Cooling | Fanless passive cooling |
| Mounting | Desktop / Wall-mount |
| Dimensions | 193.9 × 127 × 57.2mm |
| Weight | 1.0kg |
Model Configuration Options
| Part No. | CPU | Generation | Memory | HDMI | VGA / HDMI | Mini-PCIe | mSATA | M.2 | SATA | USB 3.0 | USB 2.0 | GbE | RS232 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| N8P-BDW-4278IS | i5-4278U | 4th | SODIMM | 1 | 1 | 1 | 1 | 0 | 1 | 4 | 2 | 2 | 2 |
| N8P-SKL-6157 | i3-6157U | 6th | SODIMM | 1 | 1 | 1 | 0 | 1 | 1 | 4 | 2 | 2 | 2 |
| N8P-KBL-7287 | i5-7287U | 7th | SODIMM | 1 | 1 | 1 | 0 | 1 | 1 | 4 | 2 | 2 | 2 |
| N8P-KBL-8250 | i5-8250U | 8th | SODIMM × 2 | 1 | 1 | 1 | 0 | 1 | 1 | 4 | 2 | 2 | 2 |
| N8P-WHL-8565 | i7-8565U | 8th | SODIMM × 2 | 1 | 1 | 1 | 0 | 1 | 1 | 4 | 2 | 2 | 2 |
| N8P-CML-10210 | i5-10210U | 10th | SODIMM × 2 | 1 | 1 | 1 | 0 | 1 | 1 | 4 | 2 | 2 | 2 |
| N8P-ADL-1235U | i5-1235U | 12th | DDR5 SODIMM | 1 | 1 | 1 | 0 | 1 | 1 | 4 | 2 | 2 | 2 |
| N8P-ADL-1255U | i7-1255U | 12th | DDR5 SODIMM | 1 | 1 | 1 | 0 | 1 | 1 | 4 | 2 | 2 | 2 |
Why Choose SNR-N8P?
SNR-N8P is suitable for projects that require a compact fanless industrial mini PC with reliable 24/7 operation and flexible CPU configuration.
Compared with standard consumer mini PCs, SNR-N8P provides fanless aluminium construction, wide-temperature operation, dual LAN, RS232 COM ports, Mini-PCIe expansion, watchdog support and industrial mounting options. These features make it practical for kiosks, digital signage, automation control, machine vision, network appliances and embedded commercial systems.
For applications that need a smaller embedded computer than SNR-N6 but still require industrial reliability, SNR-N8P is a balanced choice.
Related Models
SNR-IBC-N8 Fanless Industrial PC
Best for:General-purpose kiosk controller applications
SNR-N6 Industrial Mini PC
Best for:Industrial automation and multi-device serial communication
SNR-N5K Industrial Mini PC
Best for:Multi-display and graphics-intensive applications
SNR-N8P Industrial Mini PC
Best for:Compact kiosk and embedded system deployments
Related Resources
Buyer Guides
Solution Guides
Related Hardware
FAQ
What is SNR-N8P used for?
SNR-N8P is used as a fanless embedded computer for self-service kiosks, digital signage, industrial automation, machine vision, network appliances and commercial embedded systems.
Is SNR-N8P fanless?
Yes. SNR-N8P uses an aluminium passive-cooling chassis with no fan, helping reduce dust accumulation, noise and moving-part maintenance.
What processor options are available?
SNR-N8P supports Intel Core i3 / i5 / i7 processor options from 4th, 6th, 7th, 8th, 10th, 12th and 13th generations.
Does SNR-N8P support dual displays?
Yes. It supports HDMI plus VGA or a second HDMI output, depending on configuration.
How many LAN ports does SNR-N8P have?
SNR-N8P includes 2 × GbE RJ45 LAN ports.
Does SNR-N8P have COM ports?
Yes. SNR-N8P includes 2 × RS232 COM ports.
Can SNR-N8P be used for outdoor kiosks?
Yes. Its -20℃ to 60℃ operating temperature range makes it suitable for outdoor kiosk enclosures with proper mechanical and ventilation design.
Does SNR-N8P support WiFi or 4G?
Yes. The Mini-PCIe slot with SIM card holder supports 3G / 4G, WiFi and Bluetooth modules depending on configuration.
What operating systems are supported?
SNR-N8P supports Windows 7 / 8 / 10 / 11, WES 7 / 10 and Linux.
Is SNR-N8P suitable for self-service kiosks?
Yes. SNR-N8P is commonly used as a compact kiosk controller PC for self-checkout systems, hotel kiosks, visitor management terminals and ticketing machines.
What is the difference between SNR-N8P and SNR-IBC-N8?
SNR-N8P focuses on compact deployment and flexible CPU configurations, while SNR-IBC-N8 is optimized for general-purpose kiosk controller applications.
Can SNR-N8P operate 24/7?
Yes. Its fanless aluminium chassis is designed for continuous industrial operation.
Is SNR-N8P suitable for digital signage?
Yes. Dual display support and Intel Core processor options make it suitable for digital signage and information display systems.
